| MOTOR: FPT CURSOR 13 | |
|---|---|
| Configuração | 6 cilindros em linha - 12.9 |
| Potência - cv (kW)/rpm | 460-540 (338-397) / 1900 |
| Torque - Nm (kgfm)/rpm | 2000-2550 (203,9-260) / 1000 |
| Sistema de injeção | Common Rail |
| CÂMBIO: ZF TraXon (marchas: 12 + 2) | |
| Iveco S-Way 460 (6X2): 12TX2621TD | 16,69:1 / 12,92:1 / 9,93:1 / 7,69:1 / 5,90:1 / 4,57:1 / 3,66:1 / 2,83:1 / 2,17:1 / 1,68:1 / 1,29:1 / 1,00:1 | Ré 1: 15,52:1 Ré 2: 12,03:1 |
| Iveco S-Way 480 (4X2): 12TX2620TD | 16,69:1 / 12,92:1 / 9,93:1 / 7,69:1 / 5,90:1 / 4,57:1 / 3,66:1 / 2,83:1 / 2,17:1 / 1,68:1 / 1,29:1 / 1,00:1 | Ré 1: 15,54:1 Ré 2: 12,03:1 |
| Iveco S-Way 480 (6X2): 12TX2621TD | 16,69:1 / 12,92:1 / 9,93:1 / 7,69:1 / 5,90:1 / 4,57:1 / 3,66:1 / 2,83:1 / 2,17:1 / 1,68:1 / 1,29:1 / 1,00:1 | Ré 1: 15,54:1 Ré 2: 12,03:1 |
| Iveco S-Way 540 (6X4): 12TX2624TD | 16,69:1 / 12,92:1 / 9,93:1 / 7,69:1 / 5,90:1 / 4,57:1 / 3,66:1 / 2,83:1 / 2,17:1 / 1,68:1 / 1,29:1 / 1,00:1 | Ré 1: 15,54:1 Ré 2: 12,03:1 |
| DIFERENCIAL | |
| Iveco S-Way 460 (6X2): Meritor MS23-18X | 3,08:1 |
| Iveco S-Way 480 (4X2): Meritor MS23-18X | 2,85:1 |
| Iveco S-Way 480 (6X2): Meritor MS23-18X | 3,08:1 / 2,85:1 |
| Iveco S-Way 540 (6X4): Meritor MT50-168 | 3,07:1 |
| MOTOR: FPT CURSOR 13 | |||
|---|---|---|---|
| Iveco S-Way 460 (6X2) | 6 cilindros - 12.9 (Gás Natural) | 460 hp (338 kW) / 1900 rpm | 2000 Nm (203,9 kgfm) / 1000 rpm |
| Iveco S-Way 480 (4x2) | 6 cilindros - 12.9 (Diesel) | 480 hp (359 kW) / 1900 rpm | 2450 Nm (250 kgfm) / 1000 rpm |
| Iveco S-Way 480 (6x2) | 6 cilindros - 12.9 (Diesel) | 480 hp (359 kW) / 1900 rpm | 2450 Nm (250 kgfm) / 1000 rpm |
| Iveco S-Way 540 (6x4) | 6 cilindros - 12.9 (Diesel) | 540 hp (397 kW) / 1900 rpm | 2550 Nm (260 kgfm) / 1000 rpm |
| PESOS E CAPACIDADES (kg): | ||||
|---|---|---|---|---|
| Modelo | Eixo Dianteiro | Eixo Traseiro | Peso Bruto Total | Capacidade de Tração |
| Iveco S-Way 460 (6X2) | 6,200 | 21,000 | 27.200 (técnico) / 23.000 (legal) | 53,000 |
| Iveco S-Way 480 (4x2) | 6,200 | 11,000 | 17.200 (técnico) / 16.000 (legal) | 46,000 |
| Iveco S-Way 480 (6x2) | 7,100 | 21,000 | 28.000 (técnico) / 23.000 (legal) | 58,500 |
| Iveco S-Way 540 (6x2) | 7,100 | 22,000 | 29.100 (técnico) / 23.000 (legal) | 74,000 |
